MIPI C-PHY Verification

1- MIPI C-PHY Encoder module is connected to the MIPI C-PHY Decoder module. Note that the decoded wire states are the same as the data fed to the encoder. This verifies that the C-PHY encoder at the Driver side and the C-PHY decoder at the Monitor side achieve MIPI Specifications and can be integrated to the whole C-PHY Tx/Rx model

Simulation Waveform
